Muffa privata: | sì | Stato dei prodotti: | Di riserva |
---|---|---|---|
Tipo di interfaccia: | Porto di USB+Serial port+Parallel | Max Paper Size: | 20-120mm |
Velocità nera della stampa: | 2-6inch/s | Max. Resolution: | 203dpi |
Garanzia (anno): | di un anno | Servizio di assistenza al cliente: | Ritorno e sostituzione, call center e supporto tecnico online, addestramento in loco ed ispezione |
Corredo di sviluppo di software (SDK): | sì | Nome di prodotto: | Stampante termica del codice a barre di trasferimento |
Stampa del metodo: | Trasferimento termico/termico diretto | Comando di stampa: | TSPL |
Interfaccia: | Serial+USB+Parallel (norma) | Velocità di stampa: | 2~6inch/s |
Tipo di media: | Continuo, tagliato, bollettario, segno nero | I media rotolano la capacità di memoria: | 1inch (25.4mm) |
Larghezza del nastro: | Max.110mm, Min.30mm | Peso della stampante: | 2.50kg |
Stampatore Dimension: | 278x210x180mm | Tipo: | Termale |
Stile: | In bianco e nero | Uso: | Stampante del codice a barre |
Evidenziare: | Stampante termica del codice a barre di trasferimento,Stampante termica dell'etichetta di logistica,stampante termica dell'etichetta 6inch/s |
Model
|
GP-1824TC
|
GP-1834TC
|
|
Application
|
Supermarket, catering, clothing, logistics, tea, baking chain stores, etc
|
|
|
Printing method
|
Thermal transfer / thermal printing
|
|
|
Print command
|
TSPL
|
|
|
Resolution
|
203DPI
|
300DPI
|
|
Printing speed
|
2~6inch/s
|
2~5inch/s
|
|
Printing width
|
104mm
|
106mm
|
|
Storage
|
DRAM:8MB FLASH:4MB
|
|
|
Interface
|
USB + Serial port + Parallel port
|
USB + Serial port + Parallel port
|
|
Graphic
|
monochrome PCX, BMP and other image files can be downloaded to flash / DRAM
|
|
|
1D code / QR code
|
CODE128,EAN128,ITF,CODE39,EAN13,EAN13+2,EAN13+5,EAN8,EAN8+2,EAN8+5,CODABAR,POSTNET,UPC-A,UPC-A+2,UPC-A+5,UPC-E,UPC-E+2,UPC-E+5,CPOST,MSI,MSIC,PLESSEY,ITF14,EAN14,QRCODE
|
|
|
Character
|
font 0 to font 8
|
|
|
Paper type
|
Continuous paper, gap paper, folding paper, black label paper
|
|
|
Medium width (including substrate)
|
30-120mm
|
|
|
Outer diameter of paper roll
|
Maximum outside diameter of built-in roll Φ 127mm
|
|
|
Paper thickness
|
Maximum 0.254mm (10mil) minimum 0.06mm (2.36mil)
|
|
|
Roll axis size
|
25.4mm(Min)
|
|
|
Carbon ribbon outer diameter
|
Max. 67mm
|
|
|
Ribbon length
|
300m
|
|
|
Carbon belt axis size
|
1inch(25.4mm)
|
|
|
Ribbon width
|
Maximum 110mm, minimum 30mm
|
|
|
Carbon tape winding form
|
External winding type
|
|
|
Media processing
|
Tear off (standard)
Cutter, stripping (optional) |
|
|
Paper output mode
|
Front exit
|
|
|
Power input Input
|
DC24V 2.5A
|
|
|
Work environment
|
5 ~ 40 ℃, 20% ~ 90% no condensation
|
|
|
storage environment
|
- 25 ~ 55 ℃, 20% ~ 93% no condensation
|
|
|
Net weight
|
2.50kg
|
|
|
Product size
|
278x210x180mm(L*W*H)
|
|
|
Heat sensitive sheet
|
30km
|
|
|
Product certification
|
CCC,RoHS,SRRC
|
|
